Product Description
-
Three Pin Socket and Plug Suitable for Indian Socket
-
Large Dual Row LCD Display with Backlight and Annunciators
-
Memory Retention (KWh, EUT)
-
Simple, Easy and Accurate
-
Continuous Measurements
-
Counts CO2 generated by Electrical Equiptment (0.555kg CO2 is generated by using 1 KWh Energy)
-
Measures
-
TRMS Voltage (V)
-
Frequency (Hz)
-
TRMS Current (A)
-
Power Factor (PF)
-
Apparent Power (KVA)
-
Reactive Power (KVAr)
-
Active Power (KW)
-
Energy Consumption (KWh)
-
Energy Usage Time (EUT)
-
Carbon Emission (CO2 in kg)
-
Applications
-
Teaching
-
Demonstration & Testing of Electrical Energy Consumption of Household / Office Appliances.
-
It can be used in Houses, Offices, Shops, Schools, Laboratories etc
Product Specification
|
Brand |
Meco |
||
|
Product Model |
PG09 - 5A |
||
|
Product Type |
Power Guard |
||
|
Function |
PG09 - 5A |
Accuracy |
|
|
RMS Voltage (V) |
AC (Nominal) (195V ~ 26 |
±0.5% of FS |
|
|
RMS Current (A) |
(0.100 ~ 6.000) Arms |
±0.5% of FS |
|
|
Active Power @240VAC (KW) |
(0.024 ~ 1.440) KW |
±1.0% of FS |
|
|
Apparent Power @240VAC (KVA) |
(0.024 ~ 1.440) KVA |
±1.0% of FS |
|
|
Reactive Power @240VAC (KVAr) |
(0.024 ~ 1.440) KVAr |
±1.0% of FS |
|
|
Power Factor (PF) |
(0.024 ~ 0.096) KW |
>0.03 PF |
|
|
(0.096 ~ 1.440) KW |
<0.03 PF |
||
|
Line Frequency (Hz) |
45.00 ~ 55.00 Hz |
±0.2 Hz |
|
|
Active Energy (KWh) |
000000 ~ 999999 KWh |
Class 1 |
|
|
Energy Usage Time (EUT) |
Hours / Minutes |
||
|
Carbon Emission (CO in kg) |
CO2 (Kg) |
||
|
Warranty |
1 Year |
||
