Product Description
-
3½ Digit 1999 Count Large LCD Display
-
Range Selection & Single Person Push Button Operation
-
LCD with Green Backlight Function with Indicator Switch
-
Data Holding Function
-
Display with Annunciators
-
Measurement of AC Voltage upto 600VAC
-
Measurement of Phase Sequence Between (Phase - Phase Voltage) with LED Indicators & Beep Facility
-
Auto Range (Insulation Test)
-
Red LED Indicator for HV (High Voltage)
-
Inbuilt Protection Circuit to prevent the harm of reverse Voltages
-
Battery Operated with AC Adaptor
-
Suitable for Calculating PI & DAR (Manually)
-
As per EMC Standard IEC 61326-1 Class B
-
Over Voltage CAT III, 600V
-
As per Safety Standard IEC/EN 61010-1 & 61010-31
-
IP 44 Protection
Product Specification
|
Brand |
Meco |
||||
|
Product Model |
DIT 954 |
||||
|
Product Type |
Digital Insulation Testers |
||||
|
Electrical Specification |
Test voltage |
Range |
Accuracy |
Resolution |
|
|
Insulation Resistance |
1000V / 2500V / 5000V DC |
0.1M V to 200GV |
±(3%rdg 5 dgt.) |
0.01MV |
|
|
AC Voltage Measurement |
0 - 600VAC (40 - 60Hz) |
- |
±(2%rdg 5 dgt.) |
1V |
|
|
Phase Sequence Test |
100V - 450V (Phase - Phase) 40 - 60Hz |
- |
- |
- |
|
|
General Specifications |
|||||
|
Display |
31⁄2 Digit (1999 Counts) Large LCD Display with 29mm Digit Height |
||||
|
Accuracy |
±(3%rdg 5 digit) for Insulation Resistance Range ±(2%rdg 5 digit) for AC Voltage Measurment |
||||
|
Over-Range Indication |
'1' is displayed |
||||
|
Operating Temperature |
0°C to 40°C (RH < 80%) |
||||
|
Storage Temperature |
- 10°C to 50°C (RH < 75%) |
||||
|
Power |
12V (8X1.5V) (R6AA size batteries) or AC Adaptor 12VDC |
||||
|
Standard Accessories |
Insulation Resistance Measurement Test Leads for High Voltage x 1 Set, Phase Sequence Measurement Wires x 1 set, AC Adaptor x 1, 1.5V AA Batteries x 8, Heavy Duty Carry Case x 1, Instruction Manual x 1 |
||||
|
Dimensions |
190 x 155 x 75mm (approx.) |
||||
|
Weight |
900 gms including batteries (approx. ) |
||||
|
Warranty |
1 Year |
||||
