Product Description
-
Detect live voltage even when the batteries are dead
-
3 forms of AC/DC voltage indication: light, sound, and vibration for added user protection and convenience
-
Backlit LCD display and hold function for easier viewing in hard-to-test areas
-
GFCI trip for testing outlet GFCI circuits
-
Rotary field indicator
-
Built in flashlight for measuring point illumination
-
Convenient probe storage on the back
-
CAT IV 600 V, CAT III 1000 V
-
Complies with NFPA 70 E
-
CSA Approved
Product Specification
|
Brand |
Fluke |
|
Product Type |
Electrical Kit |
|
Product Model |
T PRO-1AC |
|
Temperature |
|
|
Operating Temperature |
14 to 131°F (-10 to 55°C) |
|
Storage Temperature |
-22 to 140°F (-30 to 60°C) |
|
Relative Humidity |
90%
at 32 to 86°F (0 to 30°C) |
|
Altitude |
Operating:
Approx. 6561.6' (2000 m) |
|
Battery Type/Life |
2
x AAA Batteries |
|
Shock,Vibration |
Sinusoidal vibration per MIL-PRF-28800F for a Class 2 instrument |
|
AC Bandwidth |
45 to 66 Hz |
|
Maximum Working Voltage |
1000 V AC/DC |
|
Maximum Measurable Voltage |
600 V AC/DC |
|
Duty Cycle |
Indefinitely
for voltages up to 240 V |
|
Voltage Hazard LED |
LEDs turn on at voltages >30 V AC/DC ±35% |
|
LED Voltage Indication Levels |
12 V, 24 V, 48 V, 120 V, 208 V, 240 V, 277 V, 480 V, 600 V |
|
LEDs |
LEDs turn on between 90% and 100% of the indicated voltage on the LED, except for the 12 V LED which turns on between 50% and 100% |
|
LCD Accuracy |
AC
voltage: ±(3% rdg 2 digits) |
|
LCD Resolution |
0.1
V for voltages <50 V, 1 V for voltages ≥50 V |
|
GFCI Test Current |
100
to 150 V at 6 to 9 mA AC |
|
Standard Input Test Current |
<5 mA |
|
Safety |
ISA-82.02.01 (IEC 61010-1 Mod) Second Edition, CAN/CSA-C22.2 No. 61010-1 Second Edition, IEC 61010 - 1 to 1000 V CAT III/600 V CAT IV Compliance to NFPA 70E |
|
Included Components |
Electrical Tester Voltage Detector Test Lead Wrap Test Probe |
|
Dimensions |
1.3 x 2.15 x 76" (3.3 x 5.46 x 19.3 cm) |
|
Weight |
0.6 lb (0.28 kg) |
|
Warranty |
2 Years |
